Aquinity² P35 / P70

A Product by Orlab
OverviewSpecificationsResources

Aquinity² P35/P70 versions have an independent tank from which RO water can be tapped (e.g. for glassware cleaning). The water quality from this tank depends on the feed water quality; in general the RO holds back 98% of all ions. The tank can be installed at the side or above the system or even underneath the bench.

Tapping of ultrapure water is done with our flexible but also lockable dispenser as incorporated in all membraPure ultrapure water systems. Built-in TOC monitoring is also available with the Aquinity² P35/P70 versions.

Aquinity² P35/P70 is the perfect system for a medium-sized lab.
  • Permeate rate: 10 l/h
  • Resistivity: 18.2 MOhm x cm
  • Reservoir: 35 l or 70 l
  • Flow Rate UPW: 2 l/min
  • TOC
    < 10 ppb (Reagent)
    < 3 ppb (Analytical with UV)
    < 5 ppb (LifeScience with UV and UF)
  • Endotoxins: < 0.001 EU/ml endotoxins (LifeScience)
pure water + ultrapure water quality < 2 µS/cm; Type II + 0.055 µS/cm; Type I
resistivity > 0.5 MegaOhm; Type II + 18.2 MegaOhm/cm; Type I
total organic carbon (TOC) < 10 ppb Reagent, < 5 ppb Life Science, < 3 ppb Analytical
dispensing flow rate 2.0 L/min (1.5 L/min Life Science)
production rate 10 L/min, optionally 20 L/h
bacteria < 1 cfu/mL
particulate > 0.2 µm less than 1 particulate/mL
pyrogen (endotoxins) < 0.001 EU/mL*
RNAse < 1 pg/mL*
DNAse < 5 pg/mL*
dimensions, weight, power 504 x 680 x 535 mm, 16-20 kg, 110 - 230 V
